IPD TIA16L Fuse Link 16A 415VAC Offset Slotted Bolted Tag 80kA 73mm gG For: RS32/63 RSM

Product Code: TIA16L

  • 16A rated current for reliable performance
  • Operates at 415 VAC voltage
  • High breaking capacity of 80 kA
  • Offset slotted bolted tag fuse shape
  • Compatible with RS32/63, RSM systems
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
British Standard Offset Tag Fuse Link
Brand
IPD
Series
TIA
Application
General purpose circuit protection; suitable for RS32 / 63 and RSM holders

Electrical

Utilization Category
gG / gL
Breaking Capacity
80kA
Rated Current (In)
16A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
690V AC / 460V DC
Speed Class
General purpose

Mechanical

Body Style
Offset bolted tag
Fixing Centres
73mm
Indicators
without indicator
Material
Ceramic fuse body; metal tags
Mounting
Bolt-in fuse holder
Size Code
BS88/A2
Connection/Termination
Offset bolted tags

Dimensions & Physical Data

Height
21mm
Length
84.5mm
Weight
0.04825kg
Width
21mm

Safety, Standards & Compliance

Standards and Approvals
BS88-2; IEC 60269-2

Documents

IPD Product Catalogue V17
