IPD TCP100M125 Fuse Link 125A 690VAC Offset Slotted Bolted Tag BS88/A4 Fuse 80kA 94mm gM

Product Code: TCP100M125

  • Bolt-in fuse with 125 A rated current
  • Complies with BS 88-2, AS 60269 standards
  • Rated for high voltage up to 690 VAC
  • High breaking capacity of 80 kA
  • Offset slotted bolted tag design
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
IPD

Electrical

Breaking Capacity
80kA
Rated Current (In)
125A
Rated Voltage (Ur)
690V

Mechanical

Fixing Centres
94mm

Dimensions & Physical Data

Width
Ø 41.9mm

Safety, Standards & Compliance

Standards and Approvals
BS 88-2, AS 60269, IEC 269-2-1, ASTA20

Documents

IPD Product Catalogue V17
