IPD RS200PWH Fuse Fitting 200A 690VAC White (2) Stud IP20 For: TBC TC TF

Product Code: RS200PWH

  • Accessory rated for 200 A, 690 VAC
  • Compact size: 70 mm W x 216 mm H x 137 mm D
  • Durable IP20 protection rating
  • Complies with BS 88-2, AS 60269, IEC 269-2-1
  • Easy screw mounting with stud connection
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Fitting
Brand
IPD
Series
Red Spot
Application
LV fuse fitting for utility and industrial installations

Electrical

Rated Current (In)
200A
Rated Voltage (Ur)
690V AC
No. of Poles
1P

Mechanical

Cable Entry
120 sq-mm
Colour
White
Fixing Centres
111mm
Material
Flame-retardant non-hygroscopic material
Mounting
Screw
Connection/Termination
2 stud rear connection

Dimensions & Physical Data

Depth
137mm
Height
216mm
Weight
2.1kg
Width
70mm

Environmental

IP Rating
IP20

Safety, Standards & Compliance

Standards and Approvals
BS 88-2, AS 60269, IEC 269-2-1

Documents

IPD Product Catalogue V17
