IPD RS100PWH Fuse Fitting 100A 690VAC White (2) Stud IP20 For: RS100CLINK

Product Code: RS100PWH

  • Accessory rated for 100 A current
  • Compact size: 51x140x100 mm
  • Complies with BS 88-2, AS 60269 standards
  • IP20 protection against solid objects
  • Suitable for RS100CLINK use
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Fitting
Brand
IPD
Series
Red Spot
Application
LV fuse fitting for utility and industrial installations

Electrical

Rated Current (In)
100A
Rated Voltage (Ur)
690V AC
No. of Poles
1P

Mechanical

Cable Entry
95 sq-mm
Colour
White
Fixing Centres
94mm
Material
Flame-retardant non-hygroscopic material
Mounting
Screw
Connection/Termination
2 stud rear connection

Dimensions & Physical Data

Depth
100mm
Height
140mm
Width
51mm

Environmental

IP Rating
IP20

Safety, Standards & Compliance

Standards and Approvals
BS 88-2, AS 60269, IEC 269-2-1

Documents

IPD Product Catalogue V17
