IPD OS100M125 Fuse Link 125A 415VAC Offset Slotted Bolted Tag 80kA 73mm gM For: MST100 400232

Product Code: OS100M125

  • Rated for 125 A at 415 VAC
  • High breaking capacity of 80 kA
  • Compatible with MST100, 400232
  • Offset slotted bolted tag fuse shape
  • Compact body diameter of 26.4 mm
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen

Electrical

Breaking Capacity
80kA
Rated Current (In)
125A
Rated Voltage (Ur)
415V
Speed Class
gM

Mechanical

Body Style
Cylindrical
Material
Body: Ceramic

Dimensions & Physical Data

Length
87mm
Weight
0.084kg (Approx.)
Width
Ø 21mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2, BS88-2, RoHS Compliant

Documents

IPD Product Catalogue V17
