IPD OS100 Fuse Link 100A 415VAC Offset Slotted Bolted Tag 80kA 73mm gG For: RSM100H 400231

Product Code: OS100

  • Bolt-In type with 100 A rated current
  • Handles up to 415 VAC voltage
  • High breaking capacity of 80 kA
  • Offset slotted bolted tag design
  • Compact, 26.4 mm body diameter
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen

Electrical

Breaking Capacity
80kA
Rated Current (In)
100A
Rated Voltage (Ur)
415V
Speed Class
gG

Mechanical

Body Style
Cylindrical
Material
Body: Ceramic

Dimensions & Physical Data

Length
87mm
Weight
0.059kg (Approx.)
Width
Ø 21mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2, BS88-2, RoHS Compliant
