IPD NS4 Unit Fuse-Link 4A 415VAC Clip-In BS88 Fuse 80kA gG

Product Code: NS4

  • Clip-In design for easy installation
  • Rated current of 4 A
  • Complies with IEC 60269, BS88 Part 6
  • High breaking capacity of 80 kA
  • Compatible with SC20, S32 holders
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
IPD
Series
NS
Application
Protection of cables, lines, and electrical circuits

Electrical

Utilization Category
gG
Breaking Capacity
80 kA
Fuse Class
BS88 fuse
Rated Current (In)
0.166667
Rated Voltage (Ur)
415 V AC

Mechanical

Body Style
Offset blade
Contact Material
Copper or silver-plated copper
Fixing Centres
51 mm
Mounting
Clip / bolted blade

Dimensions & Physical Data

Size
F1

Safety, Standards & Compliance

Standards and Approvals
IEC 60269 / BS88

Documents

IPD Product Catalogue V17
