IPD NS32M40 Unit Fuse-Link 40A 415VAC Clip-In BS88 Fuse 80kA gG gM

Product Code: NS32M40

  • Clip-In design for easy installation
  • Rated current of 40 A
  • Complies with IEC 60269, BS88 Part 6
  • Handles up to 415 VAC voltage
  • High breaking capacity of 80 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
BNS
Application
General purpose motor protection

Electrical

Utilization Category
gM
Breaking Capacity
80kA
Rated Current (In)
32M40A
Rated Voltage (Ur)
415V AC / 415V DC

Mechanical

Body Style
Offset blade
Indicators
without indicator
Material
Body: Ceramic
Mounting
Clip-in
Size Code
F1
Connection/Termination
Offset blades
Fuse Holder
SC32 holders

Dimensions & Physical Data

Length
61mm
Weight
0.0238kg (Approx.)
Width
Ø 13.5mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2, BS 88-2

Documents

IPD Product Catalogue V17
