IPD NS32 Unit Fuse-Link 32A 415VAC Clip-In BS88 Fuse 80kA gG

Product Code: NS32

  • 32 A rated current, ideal for various applications
  • Compliant with IEC 60269 and BS88 Part 6 standards
  • High breaking capacity of 80 kA for safety
  • Compact design with a length of 59 mm
  • Compatible with SC32 fuse holder
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
IPD
Series
NS
Application
Protection of cables, lines, and electrical circuits

Electrical

Utilization Category
gG
Breaking Capacity
80kA
Fuse Class
BS88 fuse
Rated Current (In)
32A
Rated Voltage (Ur)
415V AC

Mechanical

Body Style
Offset blade
Contact Material
Copper or silver-plated copper
Fixing Centres
51mm
Mounting
Clip / bolted blade

Dimensions & Physical Data

Size
F1

Safety, Standards & Compliance

Standards and Approvals
IEC 60269 / BS88

Documents

IPD Product Catalogue V17
