IPD NS25 Unit Fuse-Link 25A 415VAC Clip-In BS88 Fuse 80kA gG

Product Code: NS25

  • Rated for 25 A at 415 VAC
  • Complies with IEC 60269, BS88 Part 6
  • High breaking capacity of 80 kA
  • Compact design with 59 mm length
  • Compatible with SC32 fuse holder
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
BNS
Application
General purpose protection

Electrical

Utilization Category
gG
Breaking Capacity
80kA
Rated Current (In)
25A
Rated Voltage (Ur)
415V AC

Mechanical

Body Style
Offset blade
Indicators
without indicator
Material
Body: Ceramic
Mounting
Clip-in
Size Code
F1
Connection/Termination
Offset blades
Fuse Holder
SC32 holders

Dimensions & Physical Data

Length
61mm
Weight
0.0238kg (Approx.)
Width
Ø 13.5mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2, BS 88-2

Documents

IPD Product Catalogue V17
