IPD NS20M32 Clip-In Fuse Link 32A 415VAC Clip-In BS88 Fuse 80kA gG gM

Product Code: NS20M32

  • Rated for 32 A, 415 VAC applications
  • High breaking capacity of 80 kA
  • Complies with IEC 60269, BS88 Part 6 standards
  • Designed for use with SC20, S32 holders
  • Compact length of 59 mm
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
BNS
Application
General purpose motor protection

Electrical

Utilization Category
gM
Breaking Capacity
80kA
Rated Current (In)
20M32A
Rated Voltage (Ur)
415V AC

Mechanical

Body Style
Offset blade
Indicators
without indicator
Material
Body: Ceramic
Mounting
Clip-in
Size Code
F1
Connection/Termination
Offset blades
Fuse Holder
SC20 & SC32 holders

Dimensions & Physical Data

Length
61mm
Weight
0.0238kg (Approx.)
Width
Ø 13.5mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2, BS 88-2
