IPD NS16M20 Unit Fuse-Link 20A 415VAC Clip-In BS88 Fuse 80kA gG gM

Product Code: NS16M20

  • Clip-In connection for easy installation
  • Rated at 20 A, suitable for various applications
  • Complies with IEC 60269, BS88 Part 6 standards
  • Handles up to 415 VAC and 80 kA breaking capacity
  • Compatible with SC20 and S32 fuse holders
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
BNS
Application
General purpose motor protection

Electrical

Utilization Category
gM
Breaking Capacity
80kA AC / 40kA DC
Rated Current (In)
16M20A
Rated Voltage (Ur)
550V AC / 250V DC

Mechanical

Body Style
Offset blade
Indicators
without indicator
Material
Body: Ceramic
Mounting
Clip-in
Size Code
F1
Connection/Termination
Offset blades
Fuse Holder
SC20 & SC32 holders

Dimensions & Physical Data

Length
61mm
Weight
0.0173kg (Approx.)
Width
Ø 13.5mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2, BS 88-2
