IPD NS10M16 Unit Fuse-Link 16A 415VAC Clip-In BS88 Fuse 80kA gG gM

Product Code: NS10M16

  • Clip-In design for easy installation
  • Rated current: 16 A
  • Complies with IEC 60269, BS88 Part 6
  • High breaking capacity of 80 kA
  • Suitable for SC20, S32 fuse holders
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Motor - Start Fuse Link
Brand
IPD
Application
Motor-start circuit protection; use in SC20 and SC32 holders

Electrical

Utilization Category
gM
Breaking Capacity
80kA
Rated Current (In)
16A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
415V AC
Speed Class
Motor start

Mechanical

Body Style
Clip-in fuse
Indicators
without indicator
Mounting
SC20 / SC32 holders
Size Code
F1
Connection/Termination
Clip-in contacts
Fuse Holder
SC20 / SC32 holders

Dimensions & Physical Data

Weight
Not available

Documents

IPD Product Catalogue V17
