IPD NIT4 Fuse Link 4A 550VAC Offset Slotted Bolted Tag BS88/A1 Fuse 80kA 44.5mm gG

Product Code: NIT4

  • Bolt-in type with 4A rated current
  • Complies with BS 88-2, AS 60269 standards
  • High breaking capacity of 80 kA
  • Operates at up to 550 VAC voltage
  • Compatible with RS20, RSM32 holders
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
BNIT
Application
General purpose protection

Electrical

Utilization Category
gG
Breaking Capacity
80 kA AC / 40 kA DC
Rated Current (In)
0.166667
Rated Voltage (Ur)
550 V AC / 250 V DC

Mechanical

Body Style
Offset tag
Fixing Centres
44.5 mm
Indicators
without indicator
Material
Body: Ceramic
Mounting
Bolted / screwed
Size Code
A1
Connection/Termination
Offset tags
Fuse Holder
RS20 & RSM32 holders

Dimensions & Physical Data

Length
44.5 mm
Weight
0.0165 kg (Approx.)
Width
Ø 13.5 mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2, BS 88-2

Documents

IPD Product Catalogue V17
