IPD NIT25 Fuse Link 25A 550VAC Offset Slotted Bolted Tag BS88/A1 Fuse 80kA 44.5mm gG

Product Code: NIT25

  • Bolt-In type with 25 A rated current
  • Complies with BS 88-2, AS 60269 standards
  • High breaking capacity of 80 kA
  • Suitable for RS20, RSM32 holders
  • Operates at up to 550 VAC
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Series
BNIT
Application
General purpose protection

Electrical

Utilization Category
gG
Breaking Capacity
80kA AC / 40kA DC
Rated Current (In)
25A
Rated Voltage (Ur)
550V AC / 250V DC

Mechanical

Body Style
Offset tag
Fixing Centres
44.5mm
Indicators
without indicator
Material
Body: Ceramic
Mounting
Bolted / screwed
Size Code
A1
Connection/Termination
Offset tags
Fuse Holder
RS20 / RSM holders

Dimensions & Physical Data

Length
44.5mm
Weight
0.0165kg (Approx.)
Width
Ø 13.5mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2, BS 88-2

Documents

IPD Product Catalogue V17
