IPD NIT20M25 Fuse Link 25A 440VAC Offset Slotted Bolted Tag BS88/A1 Fuse 80kA 44.5mm gM

Product Code: NIT20M25

  • Rated for 25 A and 440 VAC
  • High breaking capacity of 80 kA
  • Complies with BS 88-2, AS 60269 standards
  • Offset slotted bolted tag design
  • Compatible with RS20, RSM32 holders
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Application
General purpose motor protection

Electrical

Utilization Category
gM
Breaking Capacity
80kA AC
Rated Current (In)
20M25A
Rated Voltage (Ur)
550V AC / 250V DC
Speed Class
gM motor protection

Mechanical

Body Style
British Standard fuse-link IEC BS88 Type A1
Fixing Centres
44.5mm
Indicators
No indicator
Material
Body: Ceramic, Terminal: Tin-Plated Copper
Mounting
Bolted / screwed into fuseholder or busbar
Size Code
A1
Connection/Termination
Offset slotted bolted tags

Dimensions & Physical Data

Length
56mm
Weight
0.016kg (Approx.)
Width
Ø 13.5mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2 section II; BS 88 part 2; RoHS

Documents

IPD Product Catalogue V17
