IPD IPW634 Padlockable Weatherproof Isolator 4-P 63A 415V IP66

Product Code: IPW634

  • 63 A rated current for reliable performance
  • Compact size: 82.5mm W x 167mm H x 89mm D
  • Suitable for up to 415 V applications
  • IP66 protection against dust and water
  • Four M25 gland entries for easy installation
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Weatherproof Isolator
Brand
IPD

Electrical

No. of Poles (Total)
4P
Rated Current (In)
63A
Rated Voltage (Ur)
415V

Mechanical

Cable Cross Section
25 sq-mm
Gland Entries
(4) M25

Dimensions & Physical Data

Depth
70mm
Height
166.5mm
Width
82.5mm

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
AS/NZS 3947.3:2001

Documents

IPD Product Catalogue V17
