IPD IPW352 Padlockable Weatherproof Isolator 2-P 35A 240V IP66

Product Code: IPW352

  • 35A isolator for reliable current handling
  • Compact design: 82.5mm wide, 167mm high
  • Durable IP66 protection for harsh environments
  • Supports cable sizes up to 25 sq-mm
  • Features four M25 gland entries
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Weatherproof Isolator
Brand
IPD
Application
Motor safety isolation, air-conditioning isolation and PV inverter AC isolation

Electrical

Rated Current (In)
35A
Rated Frequency
50/60Hz
Rated Voltage (Ur)
240V AC

Mechanical

Cable Entry
4 x M25 gland entries
Colour
Grey
Material
UV resistant polycarbonate
Mounting
Surface mounted
Connection/Termination
Screw terminals

Dimensions & Physical Data

Depth
89mm
Height
167mm
Length
89mm
Weight
0.56kg
Width
82.5mm

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
IEC/EN 60947-3; AS3133

Documents

IPD Product Catalogue V17
