IPD IPW201 Padlockable Weatherproof Isolator 1-P 20A 240V IP66

Product Code: IPW201

  • 20 A isolator with single pole design
  • IP66 protection for harsh environments
  • Compact size: 82.5 x 167 x 89 mm
  • Handles voltages up to 240 V, insulation at 500 VAC
  • Equipped with four M25 gland entries
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Weatherproof Isolator
Brand
IPD

Electrical

No. of Poles (Total)
1P
Rated Current (In)
20A
Rated Voltage (Ur)
240V

Mechanical

Cable Cross Section
25 sq-mm
Gland Entries
(4) M25

Dimensions & Physical Data

Depth
70mm
Height
166.5mm
Width
82.5mm

Environmental

IP Rating
IP66

Safety, Standards & Compliance

Standards and Approvals
AS/NZS 3947.3:2001

Documents

IPD Product Catalogue V17
