IPD ES50 Unit Fuse-Link 50A 415VAC Clip-In BS88 Fuse 80kA gG gM

Product Code: ES50

  • Clip-In BS88 fuse design for easy installation
  • Handles up to 50 A current at 415 VAC
  • Compact length of 69 mm
  • High breaking capacity of 80 kA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
Mersen
Application
General purpose low-voltage distribution protection

Electrical

Utilization Category
gG
Breaking Capacity
80kA
Rated Current (In)
50A
Rated Voltage (Ur)
415V AC
Speed Class
gG

Mechanical

Body Style
Offset blade
Indicators
No
Material
Ceramic body, copper alloy contacts
Mounting
Clip-in / offset blade
Size Code
F2
Connection/Termination
Offset blade

Dimensions & Physical Data

Depth
15.2mm
Height
39.5mm
Length
69mm
Weight
0.029kg (Approx.)
Width
17.1mm

Safety, Standards & Compliance

Standards and Approvals
EN 60269-2 section II; BS 88 part 6

Documents

IPD Product Catalogue V17
