IPD ES40 Unit Fuse-Link 40A 415VAC Clip-In BS88 Fuse 80kA gG gM

Product Code: ES40

  • 40 A rated current for robust performance
  • Handles up to 415 VAC efficiently
  • Compact 69 mm length design
  • High breaking capacity of 80 kA
  • Clip-In BS88 fuse type for easy installation
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Fuse Link
Brand
IPD
Series
ES
Application
General purpose circuit protection

Electrical

Suitable For
SC63H / SAFECLIP SC fuse holders
Utilization Category
gG / gM
Breaking Capacity
80kA
Rated Current (In)
40A
Rated Voltage (Ur)
415V AC

Mechanical

Body Style
Clip-in BS88
Mounting
SAFECLIP SC fuse holder
Size Code
ES
Connection/Termination
Clip-in

Dimensions & Physical Data

Length
69mm

Safety, Standards & Compliance

Standards and Approvals
IEC 60269; BS88 Part 6 ASTA 20 Certified

Documents

IPD Product Catalogue V17
