IDEC YW1P-2EQ0Y YW Series Pilot Lightwith Intergrated white LED 250V AC/DC max

Product Code: YW1P-2EQ0Y

  • Black pilot light with momentary actuation
  • Durable metal bezel construction
  • Wide operating temp: -30 to 70°C
  • High protection rating: IP66, NEMA 1, 12, 13, etc.
  • Lightweight at just 0.091 kg
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Pilot Light
Brand
IDEC
Series
YW

Electrical

Rated Current (In)
0.003A
Rated Voltage (Ur)
250V AC/DC max
Terminal Type
Screw Terminals

Mechanical

Lamp Colour
White
Lens Colour
Yellow
Lens Shape
Dome

Environmental

IP Rating
From panel front: IP65 (IEC 60529), Terminal: IP20 (IEC 60529)

Documents

IPD Product Catalogue V17
