IDEC RY2S-ULDC48 Miniature Relay DPDT 3A

Product Code: RY2S-ULDC48

  • Miniature design with 3A rated current
  • DPDT contacts, gold plated silver
  • 200k electrical operations lifespan
  • Operates from -25 to 55°C
  • Certified: CE, cRuus, CSA
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
General Purpose Miniature Relay
Brand
IDEC
Series
RY

Electrical

Actuating Voltage
33.6 DC
No. of N/C Contacts
2
No. of N/O Contacts
2
Electrical Connection
Blade Terminal
Rated Current (In)
0.125
Rated Voltage (Ur)
48 V DC
Change-Over Contacts
DPDT

Mechanical

Contact Material
Gold-plated silver
Mounting
With Sockets (DIN, Finger-Safe DIN, Through Panel, PCB)

Dimensions & Physical Data

Depth
35.6 mm
Height
27.5 mm
Width
14 mm

Environmental

Operating Temperature
–25 to +55°C (no freezing)

Documents

IPD Product Catalogue V17
