IDEC RY2S-ULAC240V Miniature Relay DPDT 3A Plug-In Terminal

Product Code: RY2S-ULAC240V

  • Rated for 3A with 240VAC coil voltage
  • DPDT contact configuration
  • Gold plated silver contacts
  • Plug-in terminal type
  • CE, cRuus, CSA approved
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
General Purpose Miniature Relay
Brand
IDEC
Series
RY

Electrical

Actuating Voltage
168 V AC
No. of N/C Contacts
2
No. of N/O Contacts
2
Electrical Connection
Blade Terminal
Rated Current (In)
0.125
Rated Voltage (Ur)
240 V AC
Change-Over Contacts
DPDT

Mechanical

Contact Material
Gold-plated silver
Mounting
With Sockets (DIN, Finger-Safe DIN, Through Panel, PCB)

Dimensions & Physical Data

Depth
35.6 mm
Height
27.5 mm
Width
14 mm

Environmental

Operating Temperature
–25 to +55°C (no freezing)

Documents

IPD Product Catalogue V17
