IDEC RV3T-1G12 PCB Terminal Relay 12VDC Coil

Product Code: RV3T-1G12

  • Compact size: 20.3 mm x 12.6 mm x 5.08 mm
  • Long mechanical life: 20 million operations
  • High insulation resistance: 100 MOhm
  • Wide operating temp: -40 to 70°C
  • CE, TUV, UL recognized approvals
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
PCB Relay
Brand
IDEC
Series
RV3T

Electrical

No. of N/C Contacts
0
No. of N/O Contacts
1
Electrical Connection
PCB Pin Terminal
Rated Current (In)
0.208333
Rated Voltage (Ur)
12 V DC
Change-Over Contacts
SPST-NO

Mechanical

Mounting
PCB

Dimensions & Physical Data

Depth
5.08 mm
Height
16.4 mm
Width
21.3 mm

Environmental

Operating Temperature
–40 to +70°C (no freezing)

Documents

IPD Product Catalogue V17
