IDEC RR2P-UAC110 Power Relay DPDT 110VAC Coil 10A Pin Terminal

Product Code: RR2P-UAC110

  • Rated for 110 VAC, 10 A
  • Durable silver contacts
  • DPDT contact configuration
  • 200,000 electrical operations lifespan
  • CE and CSA approved
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Relay
Brand
IDEC
Series
RR

Electrical

Actuating Voltage
88 V AC
No. of N/C Contacts
2
No. of N/O Contacts
2
Electrical Connection
Pin
Rated Current (In)
0.416667
Rated Voltage (Ur)
110 V AC (Coil)
Change-Over Contacts
DPDT

Mechanical

Contact Material
Silver
Mounting
With Socket (DIN Rail/Surface/Panel Mount)

Dimensions & Physical Data

Depth
35.6 mm
Height
68 mm
Width
28.6 mm

Environmental

Operating Temperature
–25 to +40°C (no freezing)

Documents

IPD Product Catalogue V17
