IDEC RQ1V-CM-A230 PCB Relay SPDT 230VAC Coil 1-Pole 12A

Product Code: RQ1V-CM-A230

  • Rated for 12 A with 230 VAC coil voltage
  • SPDT contact config with silver nickel alloy
  • Compact size: 12.7 mm W x 29 mm H x 15 mm D
  • Durable: 100k electrical & 10M mechanical ops
  • CE, cRuUS, UL Recognized standards approved
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
PCB Relay
Brand
IDEC
Series
RQ

Electrical

Actuating Voltage
184 V AC
No. of N/C Contacts
1
No. of N/O Contacts
1
Electrical Connection
PCB Pin Terminal
Rated Current (In)
0
Rated Voltage (Ur)
230 V AC
Change-Over Contacts
SPDT

Mechanical

Mounting
PCB

Dimensions & Physical Data

Depth
29 mm
Height
15 mm
Width
12.7 mm

Documents

IPD Product Catalogue V17
