IDEC RN2S-NL-D24 Miniature Power Relay 2PDT 24VDC Coil 5A

Product Code: RN2S-NL-D24

  • 24 VDC, 5 A rated for versatile use
  • 2PDT contact configuration
  • Durable silver alloy contacts
  • Wide temp range: -40 to 70°C
  • CE and cRUus approved
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Relay
Brand
IDEC
Series
RN

Electrical

Actuating Voltage
19.2 V DC
No. of N/C Contacts
2
No. of N/O Contacts
2
Electrical Connection
Blade
Rated Current (In)
0.208333
Rated Voltage (Ur)
24 V DC (Coil)
Change-Over Contacts
DPDT

Mechanical

Contact Material
Ag Alloy
Mounting
With Socket (DIN Rail/PCB)

Dimensions & Physical Data

Depth
28 mm
Height
36 mm
Width
21.5 mm

Environmental

Operating Temperature
–40 to +70°C (no freezing)
