IDEC RN2S-NL-D12 Miniature Power Relay W/Indicator DPDT 12VDC Coil 5A

Product Code: RN2S-NL-D12

  • 12 VDC, 5 A rated general-purpose relay
  • DPDT contact configuration with Ag alloy
  • Fast 20 ms operating time
  • Durable: 100k electrical, 10M mechanical ops
  • CE and cRUus approved for safety
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Relay
Brand
IDEC
Series
RN

Electrical

Actuating Voltage
9.6 V DC
No. of N/C Contacts
2
No. of N/O Contacts
2
Electrical Connection
Blade
Rated Current (In)
0.208333
Rated Voltage (Ur)
12 V DC (Coil)
Change-Over Contacts
DPDT

Mechanical

Contact Material
Ag Alloy
Mounting
With Socket (DIN Rail/PCB)

Dimensions & Physical Data

Depth
28 mm
Height
36 mm
Width
21.5 mm

Environmental

Operating Temperature
–40 to +70°C (no freezing)

Documents

IPD Product Catalogue V17
