IDEC RL2N-D-D12 Power Relay 2 DPST 12VDC Coil 25A Screw Terminal

Product Code: RL2N-D-D12

  • 12 VDC, 25 A rated power solution
  • Durable with 1M mechanical operations
  • Quick 30 ms operating time
  • Secure DIN rail mounting with screw terminals
  • IP40 protection, CE, cRuUS, RoHS, VDE approved
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Relay
Brand
IDEC
Series
RL

Electrical

Actuating Voltage
9.6V DC
No. of N/O Contacts
4
Electrical Connection
Screw Terminal
Rated Current (In)
25A
Rated Voltage (Ur)
12V DC (Coil)
Change-Over Contacts
DPST

Mechanical

Contact Material
Ag Alloy
Mounting
DIN Rail

Dimensions & Physical Data

Depth
54mm
Height
53.4mm
Width
50mm

Environmental

Operating Temperature
-25°C to 55°C
IP Rating
IP40

Documents

IPD Product Catalogue V17
