IDEC RJ2S-CL-A110 Slim Power Relay DPDT 110VAC Coil 8A Blade Terminal

Product Code: RJ2S-CL-A110

  • Slim Line design for compact spaces
  • Rated Voltage: 110VAC, Current: 8A
  • DPDT contact configuration with blade terminals
  • Durable silver nickel alloy contacts
  • IP40 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Relay
Brand
IDEC
Series
RJ

Electrical

Actuating Voltage
88 V AC
No. of N/C Contacts
2
No. of N/O Contacts
2
Electrical Connection
Blade
Rated Current (In)
0.333333
Rated Voltage (Ur)
110 V AC (Coil)
Change-Over Contacts
DPDT

Mechanical

Contact Material
AgNi
Mounting
With Socket (DIN Rail/PCB)

Dimensions & Physical Data

Depth
28.8 mm
Height
12.7 mm
Width
27 mm

Environmental

Operating Temperature
–40 to +70°C (no freezing)
IP Rating
IP40

Documents

IPD Product Catalogue V17
