IDEC RH3V2-ULDC24V Power Relay 3PDT 24VDC Coil 10A PCB Terminal

Product Code: RH3V2-ULDC24V

  • 24 VDC, 10 A rated power capacity
  • Durable silver cadmium oxide contacts
  • Long electrical life: 200k operations
  • Compact PCB terminal design
  • CE, cRuus, CSA certified for safety
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Relay
Brand
IDEC
Series
RH

Electrical

Actuating Voltage
80% max.
No. of Change-Over Contacts
3
No. of N/C Contacts
3
No. of N/O Contacts
3
Electrical Connection
Plug-in terminal
Rated Current (In)
10A
Rated Voltage (Ur)
24V DC (Coil)

Mechanical

Contact Material
Silver cadmium oxide/cadmium free (Ag-alloy)
Mounting
Din Rail/Panel/PC Board

Dimensions & Physical Data

Depth
27.5mm
Height
35.6mm
Width
31mm

Environmental

Ambient Temperature
-25°C to 40°C
