IDEC RH2V2-UAC110-120 Power Relay DPDT 110-120VAC Coil 10A PCB Terminal

Product Code: RH2V2-UAC110-120

  • 110-120 VAC, 10 A rated power device
  • Durable with 200k electrical operations
  • PCB terminal type for easy installation
  • CE, CSA, EN, UL certified for safety
  • Compact and lightweight at 37 g
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Power Relay
Brand
IDEC
Series
RH

Electrical

Actuating Voltage
80% max.
No. of Change-Over Contacts
2
No. of N/C Contacts
2
No. of N/O Contacts
2
Electrical Connection
Plug-in terminal
Rated Current (In)
10A
Rated Voltage (Ur)
110-120V AC (Coil)

Mechanical

Contact Material
Silver cadmium oxide/cadmium free (Ag-alloy)
Mounting
Din Rail/Panel/PC Board

Dimensions & Physical Data

Depth
27.5mm
Height
35.6mm
Width
21mm

Environmental

Ambient Temperature
-25°C to 40°C

Documents

IPD Product Catalogue V17
