IDEC PS5R-VB12 Switching Power Supply 85-264VAC 12VDC 350-190mA 15 Watt DIN Rail Mount

Product Code: PS5R-VB12

  • 15 W power output for efficient performance
  • Wide voltage range: 85-264 VAC, 12 VDC
  • DIN rail mounting for easy installation
  • Operates in -25 to 75°C temperature range
  • Complies with multiple international standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Switching Power Supply
Brand
IDEC
Series
PS5R-V

Electrical

Diagnostics
LED (green)
Input Voltage
85-264 V AC / 100-370 V DC
Output Current - Nominal
1.3 A
Output Current - Range
1.3 A
Output Power
15 W
Output Voltage - Nominal
12 V DC
Output Voltage - Range
10.8-13.2 V DC
Efficiency
80-82%
Terminal Type
M3.5 screw terminal

Mechanical

Mounting Style
DIN Rail

Dimensions & Physical Data

Depth
95 mm
Height
90 mm
Weight
0.140 kg
Width
22.5 mm

Environmental

Approvals / Conformity
UL508, UL1310 Class 2, ANSI/ISA-12.12.01, CSA C22.2 No.107.1, CSA C22.2 No.213, CSA C22.2 No.223, EN60950-1, EN50178, EN61204-3, CE, RoHS, TUV
Operating Temperature
-25 to 75°C
IP Rating
IP20
