IDEC HW2L-M1F01R-K Illuminated Pushbutton 0NO+1NC

Product Code: HW2L-M1F01R-K

  • Illuminated flush actuator, 22 mm diameter
  • IP65 front protection, IP20 terminal
  • Rated for 600 V insulation, 10 A thermal current
  • Durable with 5 million mechanical operations
  • Complies with UL, CE, ULKA, CSA standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Pushbutton
Brand
IDEC
Series
HW

Electrical

No. of N/C Contacts
1
No. of N/O Contacts
0
Terminal Type
Finger Safe Spring Terminal
Contact Block Thermal Current (Ith)
10:00 AM
Contact Block Rated Current (Ie)
AC-12: (440 V) 2 A, (220 V) 6 A, (110 V) 10 A, (50 V) 10 A, (24 V) 10 AAC-15: (440 V) 1 A, (220 V) 3 A, (110 V) 5 A, (50 V) 7 A, (24 V) 10 ADC-12: (220 V) 1.1 A, (110 V) 2.2 A, (48 V) 5 A, (24 V) 10 ADC-13: (220 V) 0.6 A, (110 V) 1.1 A, (48 V) 2 A, (24 V) 10 A

Mechanical

Actuator Type
Flush
Bezel Material
Plastic
Lamp Colour
Red
Lens Colour
Red
Switching Function
Momentary

Environmental

IP Rating
IP65
