IDEC HW1R-2DF20G-K Non-Illuminated Pushbutton Selector 2NO+0NC

Product Code: HW1R-2DF20G-K

  • Non-illuminated pushbutton, flush actuator
  • IP65 front protection for robust use
  • Operates in -25 to 60°C temperature range
  • Meets CE, CSA, TUV, UL standards
  • Momentary function with 2NO contacts
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Pushbutton Selector
Brand
IDEC
Series
HW

Electrical

No. of N/C Contacts
0
No. of N/O Contacts
2
Terminal Type
Finger Safe Spring Terminal
Contact Block Thermal Current (Ith)
10:00 AM
Contact Block Rated Current (Ie)
AC-12: (440 V) 2 A, (220 V) 6 A, (110 V) 10 A, (50 V) 10 A, (24 V) 10 AAC-15: (440 V) 1 A, (220 V) 3 A, (110 V) 5 A, (50 V) 7 A, (24 V) 10 ADC-12: (220 V) 1.1 A, (110 V) 2.2 A, (48 V) 5 A, (24 V) 10 ADC-13: (220 V) 0.6 A, (110 V) 1.1 A, (48 V) 2 A, (24 V) 10 A

Mechanical

Actuator Type
Flush
Bezel Material
Plastic
Switching Function
Momentary

Environmental

IP Rating
IP65
