IDEC GT3A-2AD24 Multi-Function Timer Delayed SPDT + Instantaneous SPDT 24VDC Pin Terminal

Product Code: GT3A-2AD24

  • Plug-in timer with delayed & instant SPDT contacts
  • Operates on 24 VDC with low power consumption
  • Wide temp range: -30 to 80°C
  • High insulation resistance of 100 MOhm
  • Meets CE, cUL, EN61812-1:2011 standards
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Multi-Function Timer
Brand
IDEC
Series
GT3

Electrical

Contact Type
Delayed SPDT + Instantaneous SPDT
Timing Range
0.1s to 180h
Contact Configuration
2 SPDT
Rated Current
5A
Rated Voltage
24V AC/DC

Dimensions & Physical Data

Depth
72.2mm
Height
40mm
Width
36mm

Environmental

IP Rating
IP40 (timer), IP20 (socket)
Ambient Temperature
-10 to +50°C

Documents

IPD Product Catalogue V17
