Product Code: FT1A-H40RC

Supports Ladder, Function Block & Script programming
Operates at 100-240 VAC
Suitable for temperatures from 0 to 55°C
Includes a 12-month warranty

Specifications

General

Product Type

Programmable Controller

Brand

IDEC

Series

SmartAXIS

Electrical

Analog Resolution 10bit	No. of Digital Inputs 24	Output Ratings 250V AC/10A 30V DC/10A 250V AC/2A 30V DC/2A
Input Ratings 12 V DC	Input Type Digital	Output Type Relay
Power Consumption 48 VA	Supply Voltage 100V AC - 240V AC	Terminal Type Screw Terminal

Dimensions & Physical Data

Depth

78mm

Height

90mm

Width

160mm

Environmental

Storage Temperature

-25°C to 70°C

Operating Temperature

0°C to 55°C

IP Rating

IP66F/IP20

Communication & Control

Ethernet Port Speed 10 Mbps/100 Mbps	Ethernet Ports 1	Expandable Communications 2
Fieldbus Interface 2	Serial Ports 2	USB Port 1
Supported Ethernet Protocols TCP/IP	Supported Serial Protocols RS232C/RS485/RS422

Safety, Standards & Compliance

Hazardous Location Ratings

Class I Division 2

Certifications / Approvals

UL 508 CSA C22.2 No.142 (c-UL)

Accessories & Additional Information

Development Software

Automation Organizer Software Suit

IDEC FT1A-H40RC CPU Base Module 100-240VAC 16 Analogue Outputs

Product Code: FT1A-H40RC
