Product Code: FT1A-B24RC

12-month warranty for peace of mind
Operates on 100-240 VAC relay voltage
Suitable for temps from 0 to 55°C
CE, TUV, UL certified; Class I Div 2 approved
Compact capacity of 47.4 kb

Specifications

General

Product Type

Programmable Controller

Brand

IDEC

Series

SmartAXIS

Electrical

Analog Resolution 10bit	No. of Digital Inputs 16	Output Ratings 250V AC/10A 30V DC/10A 250V AC/2A 30V DC/2A
Input Ratings 12 V DC	Input Type Digital	Output Type Relay
Power Consumption 41 VA	Supply Voltage 100 V AC - 240 V AC	Terminal Type Screw Terminal

Mechanical

Mounting Method

DIN Rail / Direct Mounting

Dimensions & Physical Data

Depth

78 mm

Height

90 mm

Width

119 mm

Environmental

Storage Temperature

-25 °C - 70 °C

Operating Temperature

0 °C - 55 °C

IP Rating

IP66F/IP20

Communication & Control

Ethernet Port Speed 10 Mbps/100 Mbps	Ethernet Ports 1	Expandable Communications 1
Fieldbus Interface 1	Serial Ports 1	USB Port 1
Supported Ethernet Protocols TCP/IP	Supported Serial Protocols RS232C/RS485/RS422

Safety, Standards & Compliance

Compliance Standards

UL508 CSA C22.2 No.142 (c-UL)

Hazardous Location Ratings

Class I Division 2

Accessories & Additional Information

Development Software

Automation Organizer Software Suit

IDEC FT1A-B24RC CPU Base Module 100-240VAC Relay 24 Analogue Outputs
