IDEC FC6A-R081 Digital Output Module 11-Pin

Product Code: FC6A-R081

  • 36-month warranty for peace of mind
  • Screw terminals with 5.08 mm pitch
  • CE, TUV, and UL certified for reliability
  • Suitable for Class I Div 2 hazardous locations
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Expansion Module
Brand
IDEC
Series
FC6 A MicroSmart PLC

Electrical

Channel Isolation
1,500V AC
Digital Inputs
0
Digital Outputs
8
Output Ratings
240V AC 2A / 30V DC 2A
Analog Outputs
0
Output Type
Relay
Power Consumption
1.44W
Terminal Type
Screw Terminal
Analog Inputs
0

Dimensions & Physical Data

Depth
73mm
Height
90mm
Width
23.6mm

Environmental

Storage Temperature
-25°C to 70°C
Operating Temperature
-25°C to 65°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Class I Division 2
Certifications / Approvals
CE, UL, TUV

Documents

IPD Product Catalogue V17
