IDEC FC6A-N16B3 Expansion Module 24VDC 16 Digital Inputs

Product Code: FC6A-N16B3

  • 36-month warranty for peace of mind
  • Rated voltage: 24 VDC
  • MIL terminal type for secure connections
  • Operates from -25 to 65°C
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Expansion Module
Brand
IDEC
Series
FC6 A MicroSmart PLC

Electrical

Channel Isolation
Optocoupler-isolated circuit
Digital Inputs
16
Digital Outputs
0
Analog Outputs
0
Input Ratings
7 mA/pt
Input Type
24V DC sink/source
Power Consumption
0.27W
Supply Voltage
24V DC
Terminal Type
MIL Terminal
Analog Inputs
0

Dimensions & Physical Data

Depth
73mm
Height
90mm
Width
23.6mm

Environmental

Storage Temperature
-25°C to 70°C
Operating Temperature
-25°C to 65°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Class I Division 2
Certifications / Approvals
CE, UL, TUV

Accessories & Additional Information

Development Software
WindLDR

Documents

IPD Product Catalogue V17
