IDEC FC6A-N08A11 Expansion Module 120VAC 8 Digital Inputs 11-Pin

Product Code: FC6A-N08A11

  • 36-month warranty for peace of mind
  • Operates at 120 VAC voltage
  • Screw terminal connection type
  • Suitable for -25 to 65°C environments
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Expansion Module
Brand
IDEC
Series
FC6 A MicroSmart PLC

Electrical

Channel Isolation
Isolated
Digital Inputs
8
Digital Outputs
0
Analog Outputs
0
Input Ratings
17 mA/pt
Input Type
100 to 120V AC
Power Consumption
0.27W
Supply Voltage
100V to 120V AC
Terminal Type
Screw terminals
Analog Inputs
0

Dimensions & Physical Data

Depth
73mm
Height
90mm
Width
17.6mm

Environmental

Storage Temperature
-25°C to 70°C
Operating Temperature
-25°C to 65°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Class I Division 2
Certifications / Approvals
CE, UL, TUV

Accessories & Additional Information

Development Software
WindLDR

Documents

IPD Product Catalogue V17
