Product Code: FC6A-K4A1

36-month warranty for peace of mind
Rated voltage: 0-10 VDC
Current options: 0-20 mA, 4-20 mA
Secure screw terminals with 5.08 mm pitch
IP20 protection rating

Specifications

General

Product Type

Expansion Module

Brand

IDEC

Series

FC6A MicroSmart PLC

Electrical

Analog Resolution 12-bit	Channel Isolation Photocoupler-isolated	No. of Analog Outputs 4
Output Ratings Voltage 0-10V, -10 to +10V (1kO min); Current 0-20mA, 4-20mA (300O max)	Analog Outputs 4	Output Type Voltage/Current
Power Consumption 0.34W	Supply Voltage 24V DC	Terminal Type Screw terminals

Mechanical

Mounting Method

DIN Rail/Panel

Dimensions & Physical Data

Depth

73.0 mm

Height

90.0 mm

Width

23.6 mm

Environmental

Storage Temperature

-25 to +70°C

Operating Temperature

-25 to 65?

IP Rating

IP20

Safety, Standards & Compliance

Compliance Standards

CE, UL, TUV

Hazardous Location Ratings

Class I Division 2

Accessories & Additional Information

Development Software

Automation Organizer / WindLDR

IDEC FC6A-K4A1 Analog Output Module 0-10VDC 11-Pin

Product Code: FC6A-K4A1
