Product Code: FC6A-K2A1

Output Module with 0-10 VDC voltage range
Handles current from 0-20 mA, 4-20 mA
Screw terminals with 5.08 mm pitch
IP20 protection for safe use
CE, TUV, UL certified for quality assurance

Specifications

General

Product Type

Expansion Module

Brand

IDEC

Series

FC6A MicroSmart PLC

Electrical

Analog Resolution 12-bit	Digital Inputs 0	Digital Outputs 0
Output Ratings Voltage: 0 to 10V DC, -10 to +10V DC; Current: 0 to 20mA, 4 to 20mA	Analog Outputs 2	Output Type Voltage/Current
Power Consumption 0.27W	Supply Voltage 24V DC	Terminal Type Screw terminals
Analog Inputs 0

Mechanical

Mounting Method

DIN rail or panel

Dimensions & Physical Data

Depth

73.0 mm

Height

90.0 mm

Width

23.6 mm

Environmental

Storage Temperature

-25 to 70 °C

Operating Temperature

-25 to 65?

IP Rating

IP20

Safety, Standards & Compliance

Compliance Standards

CE, UL, TUV

Hazardous Location Ratings

Class I Division 2

Accessories & Additional Information

Development Software

WindLDR

IDEC FC6A-K2A1 Analog Output Module 0-10VDC 11-Pin

Product Code: FC6A-K2A1
