IDEC FC6A-J8CU1 Analog Input Module 8 Digital Inputs 10-Pin

Product Code: FC6A-J8CU1

  • 36-month warranty for peace of mind
  • Screw terminals with 3.81 mm pitch
  • Operates in -25 to 65°C range
  • IP20 protection rating
  • CE, TUV, UL certified for safety
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Expansion Module
Brand
IDEC
Series
FC6 A MicroSmart PLC

Electrical

Analog Resolution
15-bit
Digital Inputs
0
Digital Outputs
0
Analog Outputs
0
Input Ratings
Thermocouple, Thermistor (1MO min); Detection current: 0.1mA max; Overload: 13V/40mA.
Input Type
Thermocouple/Thermist
Power Consumption
0.3W
Supply Voltage
24V DC
Terminal Type
Screw terminals
Analog Inputs
8

Dimensions & Physical Data

Depth
73mm
Height
90mm
Width
23.6mm

Environmental

Storage Temperature
-25°C to 70°C
Operating Temperature
-25°C to 65°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Class I Division 2
Certifications / Approvals
CE, UL, TUV

Accessories & Additional Information

Development Software
Automation Organizer / WindLDR
