IDEC FC6A-J4CN4 Analog Input Module 0-10VDC 4 Digital Inputs

Product Code: FC6A-J4CN4

  • Expansion module with 0-10 VDC voltage rating
  • Current range: 0-20 mA, 4-20 mA
  • Push-in terminal type for easy connections
  • Certified for hazardous locations (Class I Div 2)
  • CE, TUV, UL certified for quality assurance
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
Expansion Module
Brand
IDEC
Series
FC6 A MicroSmart PLC

Electrical

Analog Resolution
Up to 16 bit
Digital Inputs
0
Digital Outputs
0
Analog Outputs
0
Input Ratings
0 to 10 V DC, -10 to 10 V DC, 0 to 20 mA, 4 to 20 mA
Input Type
Voltage, current, thermocouple, RTD
Supply Voltage
12V DC, 24V DC
Terminal Type
Push-in Terminal
Analog Inputs
4

Dimensions & Physical Data

Depth
73mm
Height
90mm
Width
17.6mm

Environmental

Storage Temperature
-25°C to 70°C
Operating Temperature
-25°C to 65°C
IP Rating
IP20

Safety, Standards & Compliance

Hazardous Location Ratings
Class I Division 2
Certifications / Approvals
CE, UL, TÜV
