Product Code: FC6A-J4CN1

0-10 VDC input for versatile applications
Handles 0-20 mA & 4-20 mA current ranges
Secure screw terminal connections
IP20 protection against solid objects
CE, TUV, UL certified for safety and quality

Specifications

General

Product Type

Expansion Module

Brand

IDEC

Series

FC6A MicroSmart PLC

Electrical

Analog Resolution 16-bit	Digital Inputs 0	Digital Outputs 0
Analog Outputs 0	Input Ratings Voltage, Current, RTD, Thermocouple (1MO min V/Temp; 50O max I); Overload: 13V/40mA	Input Type Temp/Voltage/Current
Power Consumption 0.34W	Supply Voltage 24V DC	Terminal Type Screw terminals
Analog Inputs 4

Mechanical

Mounting Method

DIN Rail/Panel

Dimensions & Physical Data

Depth

73.0 mm

Height

90.0 mm

Width

23.6 mm

Environmental

Storage Temperature

-25 to +70°C

Operating Temperature

-25 to 65?

IP Rating

IP20

Safety, Standards & Compliance

Compliance Standards

CE, UL, TUV

Hazardous Location Ratings

Class I Division 2

Accessories & Additional Information

Development Software

Automation Organizer / WindLDR

IDEC FC6A-J4CN1 Analog Input Module 0-10VDC 4 Digital Inputs 10-Pin

Product Code: FC6A-J4CN1
