Product Code: FC6A-D32K4CEE

USB & Dual Ethernet ports for connectivity
Supports Ladder and Script programming
24 VDC rated voltage
Push-In terminals for easy wiring
36-month warranty for peace of mind

Specifications

General

Product Type

CPU Module

Brand

IDEC

Series

FC6 A MicroSmart PLC

Electrical

Analog Resolution 12 bits	Digital Inputs 16	Digital Outputs 16
Output Ratings 24V DC, 0.1A per point	Input Ratings 24V DC; 5mA/pt (high speed), 7mA/pt (normal speed)	Input Type 24V DC Sink/Source
Output Type Transistor Sink	Power Consumption 3.36W	Supply Voltage 24V DC
Terminal Type Push-in Terminals	Analog Inputs 1

Dimensions & Physical Data

Depth

73mm

Height

90mm

Width

70mm

Environmental

Storage Temperature

-25°C to 70°C

Operating Temperature

-25°C to 65°C

IP Rating

IP20

Communication & Control

Ethernet Port Speed 10/100 Mbps	Ethernet Ports 2	Expandable Communications Yes
USB Port 1	Supported Ethernet Protocols Modbus TCP	Supported Serial Protocols Modbus RTU

Safety, Standards & Compliance

Hazardous Location Ratings

Class I Division 2

Certifications / Approvals

CE, UL, TUV

Accessories & Additional Information

Development Software

Automation Organizer / WindLDR

IDEC FC6A-D32K4CEE CPU Base Module 24VDC 32 Digital Inputs

Product Code: FC6A-D32K4CEE
