IDEC FC6A-C16P1DE All-In-One CPU Module 12VDC

Product Code: FC6A-C16P1DE

  • Supports USB, RS-232C/RS-485 & Ethernet interfaces
  • Ladder and Script programming languages
  • 36-month warranty for peace of mind
  • Operates at 12 VDC
In Stock Low Stock Out Of Stock Please See Attributes
1

Specifications

General

Product Type
CPU Module
Brand
IDEC
Series
FC6 A MicroSmart PLC

Electrical

Analog Resolution
10 bits
Digital Inputs
9
Digital Outputs
7
Output Ratings
12V DC, 0.5A per point
Input Ratings
12V DC; 5mA/pt (high speed), 6mA/pt (normal)
Input Type
12V DC Sink/Source
Output Type
Transistor Source
Power Consumption
3.12W
Supply Voltage
12V DC
Terminal Type
Screw Terminals
Analog Inputs
1

Dimensions & Physical Data

Depth
73mm
Height
90mm
Width
95mm

Environmental

Storage Temperature
-25°C to 70°C
Operating Temperature
-25°C to 65°C
IP Rating
IP20

Communication & Control

Ethernet Port Speed
10/100 Mbps
Ethernet Ports
1
Expandable Communications
Yes
Serial Ports
1
USB Port
1
Supported Ethernet Protocols
Modbus TCP
Supported Serial Protocols
Modbus RTU

Safety, Standards & Compliance

Hazardous Location Ratings
Class I Division 2
Certifications / Approvals
CE, UL, TUV

Accessories & Additional Information

Development Software
Automation Organizer / WindLDR

Documents

IPD Product Catalogue V17
