Product Code: FC6A-C16K1DE

USB, RS-232C/RS-485, and Ethernet ports
Supports Ladder and Script programming
12 VDC rated voltage
Comes with a 36-month warranty

Specifications

General

Product Type

CPU Module

Brand

IDEC

Series

FC6 A MicroSmart PLC

Electrical

Analog Resolution 10 bits	Digital Inputs 9	Digital Outputs 7
Output Ratings 12V DC, 0.5A per point	Input Ratings 12V DC; 5mA/pt (high speed), 6mA/pt (normal/middle speed)	Input Type 12V DC Sink/Source
Output Type Transistor Sink	Power Consumption 3W	Supply Voltage 12V DC
Terminal Type Screw Terminals	Analog Inputs 1

Dimensions & Physical Data

Depth

73mm

Height

90mm

Width

95mm

Environmental

Storage Temperature

-25°C to 70°C

Operating Temperature

-25°C to 65°C

IP Rating

IP20

Communication & Control

Ethernet Port Speed 10/100 Mbps	Ethernet Ports 1	Expandable Communications Yes
Serial Ports 1	USB Port 1	Supported Ethernet Protocols Modbus TCP
Supported Serial Protocols Modbus RTU

Safety, Standards & Compliance

Hazardous Location Ratings

Class I Division 2

Certifications / Approvals

CE, UL, TUV

Accessories & Additional Information

Development Software

Automation Organizer / WindLDR

IDEC FC6A-C16K1DE All-In-One CPU Module 12VDC

Product Code: FC6A-C16K1DE
